This is a compact, easy-to-fit external shower mixer system. The shower hose is stored separately in a locker somewhere. When you want to use the shower, plug in the bayonet hose fitting on the side of the van and set the required temperature by turning the handle at the end of the shower hose.
This is a trendy shower tap used in many modern European caravans and motorhomes. It is for diaphragm pump medium-pressure systems, not for vehicles with submersible water pumps.
These units can be installed at our workshop in Silverdale. Please contact us for installation costs.
Features
- The shower head and hose are unplugged from the tap
- Bayonet connection external to mixer tap
- Easy installation with threaded BSP fittings
- Small, compact
- Allows for precise pressure flow
- Accurate temperature control
- ABS UV-rated plastic and bronze plumbing
Technical Information
- Max. pressure: 3 bar
- High-quality bronze mixer tap
- 15mm BSP hot and cold threaded connections
- Cut out hole size 105mm H x 85mm W
- 140mm H x 120mm W external mounting plate with dust cover
- Requires approx 90mm internal space for the plumbing, not including wall thickness
- The shower hose length is 1500mm
- Shower head with shut off valve
- 1-Year Factory Warranty
